It comes with a 25-foot line set
Energy Star 12K BTU Heat Pump Condenser & Wall Mount Air Handler 115 volt 22 SEER with Enhanced WiFi and 25ft Lineset
Introducing the MRCOOL® E Star DIY 4th Gen 12k BTU 22 SEER Ductless Mini-Split Heat Pump. These are ductless mini-split heat pumps with enhanced WIFI engineered to make setup not only quick and easy, but the MRCOOL DIY E Star Series is flexible enough to be installed virtually anywhere without requiring specialized tools or expensive equipment.The 12,000 BTU unit is 22 SEER and designed to heat and cool up to 500 square feet both efficiently and effectively. Our SmartHVAC app is compatible with Amazon Alexa and Google assistant. You can also control your DIY anywhere with your Apple or Android smart device with an Internet connection. Doing it yourself has never been easier with the new MRCOOL E Star DIY. This unit is shipped in two boxes.
Our Easy DIY installation: pre-charged quick connect line doesn't require special tools, equipment, or training
SmartHVAC app: WIFI control - control your DIY anywhere with your Apple or Android smart device and an Internet connection
Variable-speed DC inverter compressor technology cuts operating costs
Low ambient cooling: cooling down to 5F exterior temperatures, the ideal system for computer server rooms, greenhouses, and any other applications that require cooling all year
The unit is 22 SEER and designed to heat and cool a single 500 square foot space
7-Year compressor warranty and 5-year parts warranty
Auto-restart: - power outage? No worries, the MRCOOL DIY E star Series auto-restart has the unit running again immediately
Gold Fin® condenser: corrosion-resistant coastal living - don't worry, our condenser is built to resist long term corrosion
Louver position memory remembers so you don't need to - horizontal louver automatically moves to the same position you set the last time the unit was turned on
Automatic leakage detection technology to alert you should a problem arise
|
SEER |
22 |
|
EER |
12.7 |
|
HSPF |
10 |
|
CFM |
305/211/147 |
|
TONNAGE |
1 |
|
COOLING CAPACITY |
12000 BTU |
|
HEATING CAPACITY |
12000 BTU |
|
VOLTAGE |
110-115 V |
|
PHASE |
1 |
|
CYCLE |
60 Hz |
|
MAX FUSE BREAKER |
20 A |
|
MIN CIRCUIT AMPACITY |
15 A |
|
MOUNT TYPE |
Wall |
|
COLOR |
White |
|
COLOR FAMILY |
White |
|
MAX COVERAGE AREA |
500 sq ft |
|
ZONE CAPACITY |
1 |
|
REFRIGERANT TYPE |
R-410A |
|
REFRIGERANT VOLUME |
38.8 oz |
|
DECIBEL RATING |
23.5/31.5/38 dBA |
|
DECIBEL RATING LOW |
23.5 dBA |
|
DECIBEL RATING HIGH |
38 dBA |
|
AIR FLOW DIRECTION |
4-way |
|
NUMBER OF SPEEDS |
4 (Variable) |
|
OSCILLATION |
Yes |
|
INVERTER |
Yes |
|
MIN AMBIENT HEAT |
5 Degrees F |
|
LINE SET LENGTH |
16ft or 25ft |
|
MAX LINESET LENGTH |
82ft Max |
|
LIQUID LINE FITTING |
3/8 in |
|
LIQUID LINE SIZE |
1/4 in |
|
SUCTION LINE FITTING |
5/8 in |
|
SUCTION LINE SIZE |
1/2 in |
|
CONTROL TYPE |
LED |
|
CONDENSER FAN MOTOR RPM |
650/700/80 |
|
BLOWER MOTOR RPM |
700/850/11 |
|
FILTER TYPE |
Washable |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
No |
|
LOW VOLTAGE COMPENSATION |
No |
|
OVERLOAD PROTECTION |
Yes |
|
ADJUSTABLE THERMOSTAT |
Yes |
|
FAN ONLY OPTION |
Yes |
|
QUIET MODE |
Yes |
|
SLEEP MODE |
No |
|
AUTO COOL |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
WORKS WITH IOS |
Yes |
|
WORKS WITH ANDROID |
Yes |
|
REMOTE CONTROL INCLUDED |
Yes |
|
UL LISTED |
No |
|
CSA LISTED |
Yes |
|
CSA CERTIFIED |
Yes |
|
ETL LISTED |
No |
|
ENERGY STAR COMPLIANT |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
REGISTERED WARRANTY |
5-year Parts/7-year Compressor/1-year Remote |
|
BASE WARRANTY |
None |
|
REGISTERED PARTS WARRANTY |
5-year |
|
BASE PARTS WARRANTY |
None |
|
REGISTERED COMPRESSOR WARRANTY |
7-year |
|
BASE COMPRESSOR WARRANTY |
None |
|
REGISTERED REMOTE WARRANTY |
1-year |
|
BASE REMOTE WARRANTY |
None |
|
REGISTERED LABOR WARRANTY |
None |
|
BASE LABOR WARRANTY |
None |
|
HAS BATTERIES |
Yes |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS AEROSOL |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
PROPOSITION 65 WARNING |
No |
|
RESTRICTED STATES |
GU, PR, VI |
|
NET DEPTH |
20.55 |
|
NET HEIGHT |
33.5 |
|
NET WIDTH |
63.07 |
|
NET WEIGHT |
98.32 lbs. |
|
GROSS WEIGHT |
139.99 lbs. |
|
CONDENSER DEPTH |
13.11 in |
|
CONDENSER HEIGHT |
21.81 in |
|
CONDENSER WIDTH |
31.50 in |
|
CONDENSER WEIGHT |
78.7 |
|
AIR HANDLER DEPTH |
7.44 in |
|
AIR HANDLER HEIGHT |
11.69 in |
|
AIR HANDLER WIDTH |
31.57 in |
|
AIR HANDLER WEIGHT |
19.62 lbs |
|
FREIGHT CLASS |
250 |
